All Seals has developed a line of conductive silicone elastomers that are designed to meet the requirements outlined for the MIL-G-83528 specification.

ELECTRICALLY CONDUCTIVE SILICONES

Product Number Product Description Max V.R. (ohm/cm) Available Durometers (Shore A) MIL-DTL83528C TYPE REFERENCE
2000
2000F
SERIES
Electrically Conductive Filled with Nickel Coated Graphite Molded Sheets
.04
*** For VR values of continuous roll product please contact All Seals as VR value vary with thickness and shore A dutometer spec***
30 to 75 N/A
5000 SERIES Electrically Conductive Silicone Filled with Silver Plated Aluminum .008 55 to 65 TYPE B
5000F SERIES Electrically Conductive Fluorosilicone Filled with Silver Plated Aluminum .004 45 to 70 TYPE D
8000 AND 8000F SERIES Electrically Conductive Silicone Filled with Silver Plated Copper .004 65 to 85 TYPE A AND TYPE K
6000 AND 6000F SERIES Electrically Conductive Silicone Filled with Silver Plated Glass .006 55 to 80 TYPE M
1000 SERIES Semi-Conductive Silicone Filled with Carbon Black Filler 10 70 n/a
